Haymaster
Four Haymaster Options
3-Bale Bumper Pull, 5-Bale, 10-Bale, and 14-Bale
The 3 Bale Haymaster is a bumper pull trailer for quick and easy towing. The Gooseneck 5-Bale Haymaster is a dual-tilting bale trailer that dumps left or right, so you can feed into a pasture and haul off a field with the same trailer. The14-Bale in-line model is designed to haul 14 – 5’ rolls or 18 – 4’ rolls. All trailers are sandblasted, primed, painted, and backed by a 5-year limited warranty.
Choose Your Haymaster
Two bale trailers, one patented two-sided dumping mechanism. Pick the cradle-style 5-Bale for feeding and short hauls, or the 37-foot 14-Bale for moving a full field at once.
5-Bale Haymaster
14-Bale Haymaster
5-Bale Haymaster
Our Haymaster trailer features a dual-tilting mechanism that allows loading and unloading from either the left or the right. From feeding to hauling, we have you covered on both sides.
- Length32′ bale end load
- Capacity5 cradles, two-sided dump
- Axles2 – 6K cambered spring
- Tires4 – 235/85 R16 radial
Standard Features
- 32′ bale end load (spear end of bale to load)
- 5 cradles — each loads both left and right with patented two-sided dumping mechanisms
- 8″ channel iron neck with 3/16″ formed neck gusset
- Adjustable 2–5/16″ (25K) ball coupler (hitch)
- 1 spring-loaded drop leg jack
- Electric brakes (both axles)
- 2 – 6K cambered spring axles with 1/4″ wall thickness
- 8-hole 16″ wheels
- 4 – 235/85 R16 radial tires
- Spare tire rack only
- 5 tie-down (ratchet) straps
- Basket for strap storage
- Safety chains
- Lights meet U.S. Department of Transportation (DOT)-required specifications
- Conspicuity (reflective) tape
- Sandblasted, primed with rust-inhibitive primer, painted with 2 coats
- 5-year limited warranty
14-Bale Haymaster
Built for volume. The 14-Bale carries a full in-line load on your choice of three 7K spring axles or two 10K GD spring axles, with electric brakes on every axle.
- Length37′ long
- Width102″
- Capacity14 bales, in-line
- Axles3 – 7K or 2 – 10K GD spring
Standard Features
- 37′ long, 102″ wide
- 14 bale in-line
- 3 – 7K spring axles or 2 – 10K GD spring axles
- Electric brakes (all axles)
- Adjustable 2–5/16″ (25K) ball coupler (hitch)
- 2 single-speed drop leg jacks
- Spare tire and rack
- Lights meet U.S. DOT-required specifications
- Conspicuity (reflective) tape
- Sandblasted, primed with rust-inhibitive primer, painted with 2 coats
- 5-year limited warranty
5-Bale vs. 14-Bale Haymaster
Both models share the same dual-tilting design and finish. The difference is deck length, bale capacity and how much axle you need under it.
| Specification | 5-Bale Haymaster | 14-Bale Haymaster |
|---|---|---|
| Bale capacity | 5 bales in cradles | 14 bales in-line |
| Deck length | 32′ bale end load | 37′ long, 102″ wide |
| Loading | Spear end of bale; dumps left or right | In-line load; dumps left or right |
| Axles | 2 – 6K cambered spring, 1/4″ wall | 3 – 7K spring or 2 – 10K GD spring |
| Brakes | Electric, both axles (electric/hydraulic optional) | Electric, all axles |
| Wheels & tires | 8-hole 16″ wheels, 4 – 235/85 R16 radials | Spare tire and rack included |
| Jacks | 1 spring-loaded drop leg (2 with gearbox optional) | 2 single-speed drop leg |
| Coupler | Adjustable 2–5/16″ (25K) ball | Adjustable 2–5/16″ (25K) ball |
| Finish | Sandblasted, primed, 2 coats | Sandblasted, primed, 2 coats |
| Warranty | 5-year limited | 5-year limited |
Why Ranchers Choose the Haymaster
Built to Stay on the Road
Channel iron neck, cambered spring axles, electric brakes and DOT-compliant lighting on every build.
Finished to Last Longer
Sandblasted, primed with rust-inhibitive primer and painted with two coats — backed by a 5-year limited warranty.
Find Your Local Dealer
Gooseneck Trailer Mfg. Co., Inc. has been building farm and ranch equipment in Bryan, Texas since 1965. Tell us what you haul and we’ll point you to the nearest dealer.
Haymaster Questions, Answered
How many bales does a Haymaster trailer haul?
The 5-Bale Haymaster carries five round bales in individual cradles on a 32′ bale end load deck. The 14-Bale Haymaster carries fourteen bales in-line on a 37′ × 102″ deck.
What does “dual-tilting” mean on a Haymaster?
Each cradle uses a patented two-sided dumping mechanism, so the trailer loads and unloads from either the left or the right. You can feed on one pass and load on the next without repositioning.
What axles and brakes come on the Haymaster?
The 5-Bale runs two 6K cambered spring axles with 1/4″ wall thickness and electric brakes on both axles; electric over hydraulic brakes are optional. The 14-Bale runs three 7K spring axles or two 10K GD spring axles with electric brakes on all axles.
What colors are available?
Every Haymaster is sandblasted, primed with a rust-inhibitive primer and finished with two coats of paint in red or black.
Is the Haymaster covered by a warranty?
Yes. Both models carry a 5-year limited warranty. You can register a new trailer or submit a warranty claim online.
Where can I buy a Gooseneck Haymaster?
Haymaster trailers are sold through authorized dealers. Contact us with your location and we’ll connect you with the closest one, or browse pre-owned inventory.
