Standard Features
- 16′, 20′, 24′, 28′, and 32′ Lengths
- 6’8″ Width Up to 32′
- 7’6″ Width Up to 28′
- 6’6″ Bow Height
- Bartop on 6’8″
- Aluminum Top on 7’6”
- Open Vertical ¾” Pipe Front From Neck Down
- 3-Plank Spaced Sides
- 3/16″ Aluminum Brush Fender Material (16′, 20′, and 24′ Lengths)
- 1/4” Aluminum Brush Fender Material (28′ and 32′ Lengths)
- Schedule 40 1¼” Bow Pipes on 2′ Centers
- Double Bows at Crossgates and Tailgates
- 6″ Channel Crossmembers on 2′ Centers
- 8″ Channel Uprights
- 2”x 2” x 3/16″ Angle Floor Runners Full Length of Trailer
- Boxed Channels Over Axles
- ¼” Formed Neck Gussets
- 8″ Channel Neck (16′ and 20′ Lengths)
- 10″ Channel Neck (24′, 28′ and 32′ Lengths)
- Slipper Spring Suspension
- 235 85 R16 Radial Tire
- Spare Tire and Rack
- 2–5/16″ Adjustable Hitch (25K)
- 2”x 6″ and 2”x 8″ Treated Lumber Floor
- Floorboards Secured With ½” Spacing Between Boards and With Side Runners
- Split Tailgate
- 1 Crossgate (16′ and 20′ Lengths)
- 2 Crossgates (24′, 28′, and 32′ Lengths)
- Stainless Steel Pins
- Rubber Dock Bumper
- 1 Spring-Loaded Drop Leg Jack
- Electric Brakes (All Axles)
- Safety Chains
- 2–7K Cambered Axles With ¼” Wall Thickness (16′, 20′, and 24′ Lengths)
- 3–7K Cambered Axles With ¼” Wall Thickness (28′ and 32′ Lengths)
- Stainless Steel Center Caps
- Pipe Tailgates and Crossgates
- 5-Year Limited Warranty
Optional Features
- 6′ Width
- 7′ and 7’6″ Bow Height
- 18 oz. Vinyl-Coated Canvas Top and Front (Different Colors Available)
- 18 oz. Vinyl-Coated Canvas Side Curtains (Different Colors Available)
- 1/4″ Aluminum Brush Fender Material (16′, 20′, and 24′ Lengths)
- Aluminum Top on 6’8″ Width
- Aluminum Front on 6’8″ Width
- 4′ Enclosed Nose
- 6′ Enclosed Nose
- Straight Nose
- Sloped Nose
- Tapered Nose
- Sloped and Taped Nose (6′ Only)
- Outside Nose Door
- 4-,5-, 6-, or 7-Plank Sides
- 4,5, 6, or 7 1″ x 3″ Tube Sides
- Pipe Sides
- Solid Smooth Sides
- Punch Panel Sides
- Extra Crossgate
- Removable Crossgate
- Split Crossgate
- Slide/Swing Crossgate
- Solid Smooth Crossgate
- Slide/Swing Tailgate
- Full Escape Door
- Half Escape Door
- Horse Loading Ramp
- Rubber Torsion Axles
- 8K Suspension
- 7.2K and 8K Axles
- 235 85 R16 LR G (14 Ply) Tires
- 7-Way RV Plug
- LED Lights
- Porch Lights
- Dome Lights
- Rubber-Mounted Lights
- Top Light Bar With Backup Lights
- Extra Clearance Lights
- Spotlights
- Electric/Hydraulic Brakes
- Extra Spare Tire and Rack
- Underbody Toolbox
- 2 Single-Speed Drop Leg Jacks
- 2 Drop Leg Jacks With 2-Speed Gearbox
- Electric/Hydraulic Jack With Battery Pack
- Adjustable Eyebolt Hitch
- Rubber Floor Mats
- Rubber Wall Mats
- 4′ Dressing Room With Door, Straight, or Slant (Large Sizes Available)
- Self-Contained Removable Rear Tack Room
- Rear Tack Room
- Rear Van Doors
- 8′ Hay Rack With Ladder
- Bus Windows
- Roof Vents
- Butterfly Vents
- Padded Horse Dividers
- Saddle Racks
- Tack Hooks (5)
- Tie Hooks
- Brush Trays (3)
- Blanket Bar
- Clothes Rack
- Colored Vinyl Trim
- Cleated Rubber Floor
- Non-Cleated Rubber Floor
